400/630/1+6+12 Cage Stranding Machine.（Steresis Tension）
This equipment is mainly used for the cabling of insulated core wires such as control cables, signal cables, and small-sized plastic power cables, as well as the stranding function of copper wires and flexible copper wires (strands) .
Follow Us
Inquiry Now
↵
Main feature:
Usage: Used for parallel wires and high frequency signal transmission cable twisting and pair wrapping all in one machine.
Wrapping tension: High speed centering wrapping/Auto tension tracking,wrapping tension keep constant tension from start to end.
Traversing type: Axis-row type take-ups.There are no damag during the proccess,traversingspace and distance can be set freely.
Configuration:
φ400 Active Pay-off Stand
HH-400ZF/6+12 Main Stranding Cage:
Concentric Wrapping Head：
Meter Counter:
Ø1250 Dual-wheel Traction:
Ø400 Swing-arm Tensioner:
Ø1600 Gantry Take-up:
Electrical Control:
Product paramete：
| Item | Specification |
| Wire Diameter |
Bare Copper Wire: 1.0 ~ 4.0 mm Insulated Wire: 1.2 ~ 5.0 mm |
| Cage Speed Range |
6-Bobbin Cage: 10 ~ 90 rpm (Stepless Speed Control) 12-Bobbin Cage: 9 ~ 80 rpm (Stepless Speed Control) |
| Take-Up Line Speed | 2.0 ~ 40 m/min(Stepless Speed Control) |
| Stranding Pitch |
6-Bobbin Cage: 20 ~ 2000 mm (Stepless Adjustment) 12-Bobbin Cage: 23 ~ 2000 mm (Stepless Adjustment) |
| Wrapping Speed | 50 ~ 800 rpm(Stepless Speed Control) |
| Wrapping Pitch | 5 ~ 300 mm(Stepless Adjustment) |
| Inner Pay-Off Bobbin | PN400·(Customer to provide bobbin drawings) |
| Outer Pay-Off Bobbin | PN500 ~ PN630 |
| Outer Take up bobbin | PN800 ~ PN1600 |
| Motor Power |
6-Bobbin Cage: 22 kW (Siemens or WEG Motor) 12-Bobbin Cage: 30 kW (Siemens or WEG Motor) Wrapping Unit: 2.9 kW (Siemens or WEG Motor) Take-Up Unit: 18.5 kW (BEIDE VFD Motor) |
| Machine Center Height | 1000 mm |
| Steel wire diameter | Φ1.2-Φ3.5mm |
| Maximum cable diameter before armoring | 60mm |
| Stranding pitch | 300-1600mm |
| Maximum cage speed | 60r/min |
| Maximum line speed | 40m/min |
| Capstan wheel diameter | Ф2000mm |
| Paying-off inside cage | Ф630mm |
| Central paing-off size | Ф1000mm-Ф2000mm |
| Taking-up size | Ф1250mm-Ф2500mm |
| Main motor power | 90KW,380V,50Hz,AC |
| Central height of machine | 1000mm |
Main feature:
Usage: Used for parallel wires and high frequency signal transmission cable twisting and pair wrapping all in one machine.
Wrapping tension: High speed centering wrapping/Auto tension tracking,wrapping tension keep constant tension from start to end.
Traversing type: Axis-row type take-ups.There are no damag during the proccess,traversingspace and distance can be set freely.
| Item | Component Description | Quantity | Notes |
| 1 | φ630 End-shaft Type Pay-off Stand | 1 set | - |
| 2 | Cross-type Wire Guide Stand | 1 set | - |
| 3 | HH-B400CZ/6+12 Main Stranding Cage | 1 set each | 6-bobbin and 12-bobbin configurations |
| 4 | Stranding Die Holder | 2 sets | - |
| 5 | φ400 Concentric Paper Wrapping Head | 1 set | - |
| 6 | Length Counter (Mechanical & Electrical) | 1 set | Dual measurement system |
| 7 | φ1250 Dual-wheel Dual-drive Take-up Unit (Natural Strand Separation) | 1 set | - |
| 8 | φ1600 Gantry-type Take-up and Wire Arranging Stand | 1 set | - |
| 9 | Electrical Control System | 1 set | - |
| 10 | Main Machine Column Safety Guard Rail | 1 set | - |
| 11 | Foundation Bolts | Full set | All required mounting hardware |
Configuration:
φ400 Active Pay-off Stand
| Component | Specification | Details |
| Pay-off Bobbin | PN400 | |
| Structure | Pneumatic clamping, motorized lifting, end-shaft type | |
| Tension Control | Swing arm storage device with mechanical counterweight tension adjustment (calibrated scale) | |
| Drive System | Active pay-off with PID control (VFD + angular displacement sensor) | High reliability |
HH-400ZF/6+12 Main Stranding Cage:
| Component | Specification | Details |
| Drive System | Individual motor drive with direct-coupled gear reducer (no timing belts) | Hardened gears (carburized & ground) |
| Construction | Hollow shaft, cage discs, bobbin holders, strand guides | Includes hemp wrapping device |
| Alignment | Dual spherical roller bearings support | High concentricity |
| Untwisting | Independent planetary gear system (6 gears) | Full untwisting capability |
| Active Pay-off | motors with aluminum buffer wheels | Magnetic hysteresis clutch for constant tension |
| Bobbin Mounting | Manual loading with dual locking (trapezoidal thread + spring pin) | |
| Braking | Planar pneumatic brake |
Concentric Wrapping Head：
| Component | Specification | Details |
| Core Passage | Ø51mm | |
| Tape Spool | Ø400×Ø76×(10-80)mm | 10 spool capacity |
| Speed | 50-800 rpm (stepless) | |
| Pitch | 3-300mm (adjustable) | |
| Motor | 2.2kW VFD | |
| Tension Control | Magnetic hysteresis brake + PLC | Touchscreen setting |
| Safety | Emergency stop button |
Meter Counter:
| Component | Specification | Details |
| Type | Dual mechanical/electronic | |
| Wheel Circumference | 500mm | |
| Max Length | 9999m | |
| Accuracy | ≤0.4% | |
| Drive | Dual active wheels | Spring-loaded pressure |
| Sensor | Non-contact magnetic probe |
Ø1250 Dual-wheel Traction:
| Component | Specification | Details |
| Wheels | Ø1250mm (dual active drive) | Natural strand separation |
| Speed | 2-40 m/min (stepless) | |
| Motor | 18.5kW | |
| Grooves | 6 U-shaped | |
| Design | Staggered angle + support rod | Prevents cable pinching |
Ø400 Swing-arm Tensioner:
| Component | Specification | Details |
| Wheels | Ø400mm (groove base) | |
| Groove | Ø40mm radius | |
| Tension Control | Pneumatic (pressure valve) | Lever principle |
| Feedback | Angular displacement sensor | Speed signal to take-up motor |
Ø1600 Gantry Take-up:
| Component | Specification | Details |
| Bobbin Size | PN800-PN1600 | |
| Capacity | 5T max | |
| Speed | 45 m/min max | |
| Motors |
Take-up: 4kW Traverse: 0.75kW Lift: 0.75kW Clamp: 0.75kW |
|
| Features |
Automatic centering Motorized bobbin handling PID control via tension feedback |
|
| Safety | Clamping/limit switches |
Electrical Control:
| Component | Specification | Details |
| Power | 380V±10%, 50Hz (3P+PE+N) | |
| Components |
Siemens VFDs & PLC Schneider low-voltage Siemens HMI WEG |
|
| Safety |
Delayed start after alarm Emergency stops on all stations |
Product paramete：
| No | Item | Data |
| 1 | Power | 37.5KW |
| 2 | Bucketcapacity | 2.8 M3 |
| 3 | Operating weight | 125Ton |
| 4 | Max. tractive force | 96kN |
| 5 | Max. breakout force | 96kN |
| 6 | Tipping load | 60kN |
| 7 | Engine displacement | 6750ml |
| 8 | Max. torque | 500N.m |
